    CHCNAV M1 SINOV BASE STATION / IBASE/T1 Gps For Land Surveying Cheap Price Gnss Receiver RTK 624 Channels

    Ask Lasest Price
    Brand Name : CHC
    Model Number : M1
    Certification : CE
    Price : 2000/complete set
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 5000pc per year
    • Product Details
    • Company Profile

    CHCNAV M1 SINOV BASE STATION / IBASE/T1 Gps For Land Surveying Cheap Price Gnss Receiver RTK 624 Channels

    CHCNAV M1 SINOV BASE STATION / IBASE/T1 Gps For Land Surveying Gnss Receiver RTK 624 Channels

    CHCNAV M1 SINOV BASE STATION / IBASE/T1 Gps For Land Surveying Cheap Price Gnss Receiver RTK 624 ChannelsCHCNAV M1 SINOV BASE STATION / IBASE/T1 Gps For Land Surveying Cheap Price Gnss Receiver RTK 624 ChannelsCHCNAV M1 SINOV BASE STATION / IBASE/T1 Gps For Land Surveying Cheap Price Gnss Receiver RTK 624 Channels


    ProjectContentParameter
    Receiver characteristicssatellite trackingGPS+BDS+Glonass+galileo+QZSS, supporting the third generation of Beidou, achieving 5 stars and 16 frequencies
    number of channels624 channels
    operating systemLinux system
    Initialization time
    Initialization reliability>99.99%
    Receiver appearancebutton1 dynamic/static switch key, 1 power key
    Indicator light1 differential signal light, 1 satellite light
    Display screen1 LCD display
    Nominal accuracyStatic accuracyPlane accuracy: ±(2.5+ 0.5×10-6×D) mm
    Elevation accuracy: ±(5+0.5×10-6×D) mm
    RTK accuracyPlane accuracy: ±(8 + 1×10-6×D) mm
    Elevation accuracy: ±(15+ 1×10-6×D) mm
    Single machine accuracy1.5m
    Code difference accuracyPlane accuracy: ±(0.25+ 1×10-6×D) m
    Elevation accuracy: ±(0.5+ 1×10-6×D) m
    Electrification parametersBatteryRemovable 14000mAh lithium battery, support base station 12+ hours battery life
    External power supplyThe host can be powered by DC power supply, 220V AC power supply, and can directly power the host through the radio (9-24) V DC
    Physical propertiessizeΦ160.54 mm*103 mm
    weight1.73kg
    MaterialMagnesium alloy AZ91D body
    Operating temperature-45℃~+85℃
    storage temperature-55℃~+85℃
    humidity100% non-condensing
    Waterproof and dustproofIP68 level
    Shock vibrationIK08 level
    Anti-dropResistance to free fall of 2 meters
    Data communicationI/O interface1 external UHF antenna interface
    1 seven-pin data port interface, support power supply, differential data output
    1 nano sim card slot
    Built-in esim, free of charge for surveying and mapping for three years at the factory
    Radio stationBuilt-in transceiver, power: up to 5W
    Network moduleSupport 4G full Netcom
    Wi-Fi802.11 b/g/n
    Blue toothBT 4.0, backward compatible with BT2.x, protocol support Win/Android/IOS system
    NFCSupport NFC flash connection
    Data outputOutput formatNMEA 0183, binary code
    output methodBT/Wi-Fi/RS232/Serial
    Static storagestorage formatDirect recording of HCN, HRC, RINEX, compressed RINEX
    storageStandard 8GB storage, support space protection
    Download methodFTP remote push + local one-click download, HTTP download
    ReceiverSuper twinSupport radio + network two-way data differential at the same time, provide comprehensive data services
    one-button startChinaTest researches and develops data link concurrent communication technology, and the base station is set up immediately
