    FOIF High Precision Digital Auto Level EL302A

    Ask Lasest Price
    Brand Name : FOIF
    Model Number : EL302A
    Certification : CE
    Payment Terms : T/T, L/C, Western Union
    • Product Details
    • Company Profile

    FOIF High Precision Digital Auto Level EL302A

    FOIF Digital Auto Level EL302A


    FOIF High Precision Digital Auto Level EL302A


    • Easy one-touch operation, simply push the red button
    • Quick height and distance result - the reading is displayed almost instantly
    • Reliable and error-free reading, even in dim light conditions
    • Quicker and easier than an optical level
    • Standard deviation of 1km double run: ≤±0.6mm(Electronic reading with Invar staff)
    • Far measuring range: ≧105m
    • On board program, height difference measurement between backsight and foresight
    • Internal memory for data storage, support SD card
    ModelEL302A
    Accuracy
    Standard deviation of km double run
    Electronic measurementinvar staff+/-0.6mm*
    standard staff+/-1.0mm*
    Optical measurement+/- l.5mm*
    Electronic measurement
    Time for single measurement≤2s
    Range2-105m
    Measurement modesSingel, average, tracking
    Display resolution(m/in selectable)
    Height0.1mm/0.0001ft
    Distance1mm/0.001ft
    Telescope
    Clear objective aperature45mm
    Magnification30x
    Field of view at 100m2.3m
    Shortest focus distance1.0m
    Automatic compensator
    Working range14'
    Setting accuracy+/-0.5"
    Power
    Battery2000mAh Ni-MH rechargeable
    Continuous operating time12 hours
    Measurement programs
    On-board programsBF, BFFB, BFBF, BBFF, FBBF,
    Stake out, intermediate
    Onboard adjustmentYes
    Others
    Memory3000 points, support SD card
    DisplayLCD, 7lines*32characters
    KeyboardAlphanumeric keyboard
    InterfaceUSB, RS232 optional
    Sensitivity of circular level8'/2mm
    Water and dusp protectionIP54
    Operating temperature-20°C~50°C
    Net weight3kg
