| Aircraft |
| The weight(with out accessories) | 905 g |
| The biggest weight | 1100 g |
| Size |
| Folder | 214×91×84mm |
| Unfolder | 322×242×84mm |
| Unfolder +searchlight | 322×242×114mm |
| Unfolder +Night lights | 322×242×101mm |
| Unfolder +megaphone | 322×242×140mm |
| Diagonal wheelbase | 354 mm |
| Maximum rate of rise | 5 m/s (s mode [1]) 4 m/s (P mode) 4 m/s (s mode with accessories [1]) 4 m/s (P mode with accessories) |
| Maximum rate of descent | 3 m/s (s mode [1]) 3 m/s (P mode) |
| Maximum horizontal speed | 72km/h (S mode, calm environment near sea level) 50km/h (P mode, calm environment near sea level) |
| Maximum flight altitude | 6000 meters |
| Maximum flight time | 31 minutes (25km/h in a calm environment with constant speed) |
| Maximum hover time | 29 mins (calm environment) 27 mins (turn on night light) 28 mins (turn off night light) 22 minutes (searchlight on) 26 minutes (searchlight off) 25 minutes (turn on the shoutout) 26 minutes (turn off the
shoutout) |
| Maximum resistance to wind speed | Level 5 wind |
| Maximum tilt Angle | 35° (S mode, with remote control) 25° (P mode) |
| Maximum angular velocity of rotation | 200°/s (s mode) 100°/s (P mode) |
| Operating temperature | -10°C -40°C |
| GNSS | GPS+GLONASS |
| Hover precision | |
| Vertical | ± 0.1m (when visual positioning works normally)
± 0.5m (when GPS is working normally) |
| Horizontal | ± 0.3m (when visual positioning works normally)
± 1.5m (when GPS is working normally) |
| Working frequency | · 2.400-2.4835 GHz;
5.725-5.850 GHz
|
| Transmitted power (EIRP) | 2.400 - 2.4835 GHz
FCC:≤26 dBm
CE:≤20 dBm
SRRC:≤20 dBm
MIC:≤20 dBm
5.725 - 5.850 GHz
FCC:≤26 dBm
CE:≤14 dBm
SRRC:≤26 dBm
|
| Airborne memory | 24GB
|
| Dual light infrared camera | Angle of view: about 85° 35 mm format equivalent focal length: 24 mm Aperture: f / 2.8 For focus: 0.5 m to infinity |
| The sensor | Uncooled vanadium oxide microbolometer |
| The lens | Angle of view: 57°(HFOV) aperture: f/1.1 |
| Sensor resolution | 160×120
|
| pixel spacing | 12 μm
|
| Wavelength range | 8-14 μm
|
| Photo size [2] | 640×480(4:3)；640×360(16:9)
|
| Photo shooting mode | A single shot
Multiple BURST shots: 3/5/7
Timed shooting: 2/3/5/7/10/15/20/30/60 s |
| Video resolution | 640×360 @8.7fps
|
| Temperature measurement accuracy | High gain mode: up to 5% (typical value)
Low gain mode: up to 10% (typical value) |
| Scene dynamic range | High gain mode: -10° to +140°C
Low gain mode: -10° to +400°C |
| Image format | JPEG
|
| Video format | MP4,MOV (MPEG-4 AVC/H.264)
|
| |
| Clud Desk | |
| Structural design scope | Pitch: -135°- +45°
Translation: -100°- +100° |
| Rotatable range | Pitch: -90°- +30°
Translation: -75°- +75° |
| A stable system | 3 axis mechanical head (pitch, roll, translation) |
| Maximum control speed | 120°/s
|
| Angular jitter | ±0.005°
|
| |
| Dual-light visible-light camera |
| Image sensor | 1/2.3-inch CMOS; 12 million effective pixels |
| The lens |
|
5/5000 ISO range | Video: 100-3200 (automatic)
Photo: 100-1600 (automatic) |
| Maximum photo size | 4056×3040(4:3)；4056×2280(16:9)
|
| Photo shooting mode | A single shot
Multiple BURST shots: 3/5/7
Timed shooting: 2/3/5/7/10/15/20/30/60 s |
| Video resolution | 4K Ultra HD:3840×2160 30p
2.7K:2688×1512 30p
FHD:1920×1080 30p
|
| Video maximum code stream | 100 Mbps
|
| Image format | JPEG
|
| Video format | MP4,MOV (MPEG-4 AVC/H.264)
|
| Perception system | |
| Perceptual system type | Omni-directional sensing system [3] |
| The Place ahead | Accurate range: 0.5 to 20 m
Detection range: 20 to 40 m
Effective obstacle avoidance speed: flight speed ≤ 14m/s
Angle of view (FOV) : 40° horizontal, 70° vertical |
| The Place Back | Accurate range: 0.5 to 16 m Detection range: 16 to 32 m Effective obstacle avoidance speed: flight speed ≤ 12m/s Angle of view (FOV) : 60° horizontal, 77° vertical
|
| Up | Effective height measurement: 0.5-11m
Detection range: 11 to 22 m |
| Down | Effective height measurement: 0.5-11m
Detection range: 11 to 22 m |
| The left and right | Detection range: 0.5 to 10 m
Effective obstacle avoidance speed: flight speed ≤ 8m/s
Angle of view (FOV) : 80° horizontal, 65° vertical |
6/5000 Efficient use environment | Front, rear, left and right:
The surface has rich texture and sufficient lighting conditions
(>15 lux, normal indoor fluorescent lamp irradiation
environment)
Top: the surface is a diffuse material with a reflectance of 20%
>
(walls, trees, people, etc.)
Below: the ground is rich in texture and light
(> 15 lux, normal indoor fluorescent lamp irradiation
environment) the surface is a diffuse reflection material and the
reflectivity of > is 20%
(walls, trees, people, etc.) |
| Zoom camera |
| Image sensor | 1/2.3-inch CMOS; 12 million effective pixels |
| The lens | Visual Angle: about 83° (24mm); About 48° (48mm)
Equivalent focal length: 24-48 mm
Aperture: f/2.8 (24mm) -f/3.8 (48mm)
For focus: 0.5 m to infinity |
| ISO range | Video:
100-3200.
Photo:
100-1600 (automatic)
100-3200 (manual) |
| The shutter speed | Electronic shutter: 8-1/8000 s |
| Maximum photo size | 4000×3000
|
| Photo shooting mode | A single shot
Multiple BURST shots: 3/5/7
Automatic envelop exposure (AEB) : 3/5 @0.7EV step
Timed shot (interval: 2/3/5/7/10/15/20/30/60 seconds RAW:
5/7/10/15/20/30/60 seconds) |
| Video resolution | 49:3840×1·203 24/25/30p
2 . 7K: 2688×1512 24/25/30/48/50/60p
24/25/30/48/50/60/120p FHD: 1920×1080 |
| Video maximum code stream | 100Mbps
|
| Color pattern | D-Cinelike
|
| File system support | · FAT32(≤ 32 GB )；exFAT(> 32 GB) ·
|
| Image format | JPEG,DNG (RAW)
|
| Video format | MP4 / MOV (MPEG-4 AVC/H.264)
|
| The remote control |
| Working frequency | Working frequency |
17/5000 Maximum signal effective distance (no interference, no occlusion) | 2.400 - 2.483 GHz; 5.725 - 5.850 GHz FCC: 8000m
CE: 5000m
SRRC: 5000m
MIC: 5000m
|
| Operating temperature | 0 ℃ and 40 ℃ |
| Transmitted power (EIRP) | 2.400 - 2.4835 GHz
FCC:≤26 dBm；CE:≤20 dBm；SRRC:≤20 dBm； MIC:≤20 dBm
5.725 - 5.850 GHz
FCC:≤26 dBm；CE:≤14 dBm；SRRC:≤26 dBm
|
| Built-in battery | Built-in battery |
| Charging time | Two hours and 15 minutes |
| Working current/voltage | 1800mA ⎓ 3.83V
|
| Mobile support | Thickness 6.5-8.5 mm, maximum length 160 mm |
| Remote control size (ordinary version) | Folding: 145×80×48mm (length × width × height)
Expand: 190×115×100mm (length × width × height) |
| Support interface types | · Lightning, Micro USB (Type-B), USB Type-C™
|
| The charger |
| Input | 00-240V, 50-60Hz, 1.8A |
| Output | Main: 17.6 V ⎓ ⎓ 3.41 A or 17.0 V 3.53 A
USB: 5.0 V ⎓ 2.0 A |
| Voltage | 17.6±0.1V
|
| Rated power | 60W
|
| The searchlight |
| |
| |
| Dimensions | 68×60×41mm
|
| Port | USB Micro-B
|
| The scope of work | 30 m
|
| power | The largest 26 w |
| Intensity of illumination | FOV17°, Max. : 11lux @ 30m |
| Intelligent flight battery |
| capacity | 3850 mAh |
| A typical voltage | 15.4V
|
| Full charge pressure | 17.6V
|
| The battery type | LiPo |
| energy | 59.29 Wh
|
| The weight | About 297 g |
| Charging environment temperature | 5℃ - 40℃
|
| Working temperature | - 10 ℃ to 40 ℃ |
| Heating mode | Manual heating; Automatic heating |
| The heating temperature | - 20 ℃ and 6 ℃ |
| Heating time | 10/5000 600 seconds (maximum) |
| Heating power | 35W (maximum) |
| Charging time | 90 minutes |
| Maximum charging power | 80W
|
| Night lights |
| Overall dimensions | 68mm×40mm×27.8mm
|
| interface |
USB Micro-B
|
| power | An average of 1.6 W |
| The scope of work | 5000 meters |
| Luminous intensity | Minimum direction: 55cd;
Average upper hemisphere luminous intensity: 157cd |
| APP/figure |
| Figure and scheme | OcuSync 2.0
|
8/5000 Mobile App | DJI PILOT
|
| Real-time image quality | The remote control:
30 FPS 1080 p / 720 p @ @ 30 FPS |
| Maximum bitrate of real-time graph transmission | 40Mbps
|
| Time delay | 120 - 130 ms
|
| Mobile device system version requirements | IOS 10.0 or later Android 5.0 or later |
| Propaganda apparatus |
| Size | 68×55×65 mm
|
| Port | USB Micro-B
|
| Power | The largest 10 w |
| Decibel (international standard) | 100db@1m or less |
| stream | 16kbps
|
| Memory card |
| Support memory card type | MicroSD card
Maximum support 128GB capacity,
The transmission Speed reaches the Micro SD card with uhs-i Speed
Grade 3 rating |
| Annotations | |
[1] remote control is required [2] with the advanced real-time digital enhancement technology, the
thermal imaging image resolution of "yu" Mavic 2 industry
dual-light version is much higher than the native resolution of
infrared sensor. [3] omnidirectional perception includes front, back, left, right,
upper and lower six directions, but not 360 degree omnidirectional
coverage. Among them, left-right perception can only provide
auxiliary obstacle avoidance function in intelligent following and
tripod mode and limited environment. The loss caused by lateral
flight hitting obstacles (including intelligent following and
tripod mode) is not covered by DJI warranty. The sensing system can
only assist flight safety under limited environmental conditions,
and cannot replace the judgment and control of the operator. Please
always pay attention to the surrounding environment and APP
warnings during flight to ensure safe flight. [4] all the above data are measured under the latest version of
firmware. Please pay attention to and keep the current firmware as
the latest version to obtain the best performance. [4] the maximum take-off altitude means that the aircraft can take
off within this altitude range. By default, the maximum flight
height of the aircraft is limited to 120 meters (up to 500 meters).
The height limit varies in different countries/regions. Please
contact the local aviation management department to understand the
actual height limit, and strictly abide by local laws and
regulations when flying. |
