Sub-Meter Industrial Plate HV-T700

Ask Lasest Price
Brand Name :	Huaneng Wei Tong
Model Number :	Huaneng Wei Tong HV-C30W Portable Solar Charging Power Supply System
Certification :	CE
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	5000000 per pc
Delivery Time :	3-5 work days after the goods are paid

Add to Cart

Product Details
Company Profile

Sub-Meter Industrial Plate HV-T700

The HV-T700 is a GPS GLONASS dual-system sub-meter industrial panel with a 7-inch fully hardened capacitive touch screen. The industrial three defense class of the IP67, visible in outdoor sunlight, conforms to the military protection class, resists the drop of 1.8 meters at any angle, and has a four-core processor. Built-in WiFi, Bluetooth, gyroscope and other modules, using the most advanced process structure design, the fuselage lightweight, easy to carry, durable, built-in 11000 Ma high capacity battery, to ensure a long time field work.

Sub-Meter Industrial Plate HV-T700

Product Features :

Data acquisition:

Loading TMAPPER mobile GIS data acquisition system, using online and offline working mode, remote sensing image map, easy sampling points, measuring area and other field

measurement work, and can load various vector format maps.

Navigation function:

GPS accuracy: sub-meter accuracy.

Can accept GPS, GLONASS, Galilo and QZSS and other systems. Support A-GPS wide area differential signal: support

MSAS, SBAS / WAASA EGNOS.

Communication function:

SIM card interface: support, general 1.8 / 3.3 V SIM card. 2G:850/900/1800/1900MHZ.

3G: 850/2100MHZ , 850/1900MHZ , 900/1900MHZ. WIFI:802.11B/G/N direct connection. Bluetooth:BT4.0 (A2DP+EDR).

Charging / data interface: USB Micro 5 Pin.

Camera function:

Post-8 million pixels auto-focus preposition 5 million

pixels.

Sub-Meter Industrial Plate HV-T700

Data post-processing function:

Domestic data post-processing software supports the import and export of various data formats (excel / KMLT / TXT), and also supports the import and export of data from many GPS brands such as Jiaming, Magellan ZYSTAR and so on. It has the functions of field drawing and printing.

Additional function :

Built-in compass, gyroscope, gravity sensor, motion, gravity, geomagnetic sensor.

Detailed technical specifications of HV-T700:

	Processor			1.5GHz eight-core processor

	Operating	system		Android 4.4.2
	(OS)			Android 4.4.2
	(OS)
	Memory capacity			3G RAM + 32G ROM

	Memory card			Built-in TF card interface, maximum support for 64GB extension
				IP67, fall protection conforms to MIL-STD-810G / R 516.6% Procedure IV
	Three defense grade			military protection grade, up to 1.8m drop at any angle above 2 tons static
				pressure test
Basic
Basic	RFID			Optional
characteri	RFID			Optional
characteri	Fingerprint	scan	/
stics	Fingerprint	scan	/
stics	one-dimensional			Optional
	one-dimensional			Optional
	code scan

	Size (mm)			20413621mm(L×W×H)
	Weight (g)			650g

	Working temperature			-30°C - 65°C
	Storage temperature			-40°C - 80°C

	Relative humidity			5% to 95% in non-condensed state
	Operational altitude			Maximum working height: 4500m (15000 ft)
Display	Display screen			7.0 "IPS / AFFS full viewing angle" 1, 000 lumens visible in the sun
characteri	Touch screen			Surface hardness of fully hardened capacitive touch screen greater than 8H
stic
stic	Resolution ratio			1024*600

Sub-Meter Industrial Plate HV-T700

Language :

Supports more than 100 languages including Chinese, English, Spain, Russia,Portugal, etc

Battery : 11000mAh large capacity lithium battery
