    CHC Brand Huayi GPS E91 GNSS Receiver with 624 Channels for Land Survey GPS

    Ask Lasest Price
    Brand Name : Huayi
    Model Number : E91
    Certification : CE
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 1000 per year
    • Product Details
    • Company Profile

    CHC Brand Huayi GPS E91 GNSS Receiver with 624 Channels for Land Survey GPS

    CHC Brand Huayi GPS E91 GNSS Receiver with 624 Channels for Land Survey GPS

    Specification:


    modelCHC E91
    GnssChannel624
    Satellite TrackedGPS L1CA/L1P/L1C/L2P/L2C/L5
    GLONASS G1, G2, G3
    Galileo E1, E5a, E5b, ALTBOC, E6
    QZSS L1, L2 L5,
    BeiDou B1I, B2I, B3I, B1C, B2a, B2b, ACEBOC
    SBAS Ll, L5

    Update rate5 Hz, up to 50 Hz
    Performance Specifications
    Signal Reacquisition< 1 sec
    Hot Start< 10 sec
    Initialization Reliability> 99.9%
    Memory8 GB
    Real-Time Accuracy (rms)
    Static Accuracy

    Horizontal:3mm + 1ppm

    Vertical:5 mm + 1 ppm

    RTK Accuracy

    Horizontal:8 mm + 1 ppm

    Vertical:15 mm + 1 ppm

    Code DifferentialHorizontal:0.4 m
    SBAS AccuracyHorizontal:0.8 m
    Communication
    7-pinConnect to external power and radio
    USBFor charging and data transmission
    CellularGlobal 4G
    BluetoothV4.1
    WIFI802.11 ac/n/b/g/n
    WebUI

    Update firmware, manage settings and

    status, download data

    Date formats

    CNR input and out put

    RTCM 2.x, RTCM 3.x input and output
    NMEA 0183 output
    HCN, HRC and RINEX 2.11, RINEX 3.02
    NTRIP Client, NTRIP Caster

    Electronic BubbleSupport
    Dimensions160*158*96mm , 1.55KG
    ShockSurvive a 2 m pole drop on concrete floor 1.2 m free drop
    5-pin lemo portconnecting external power supply and external radio
    SIM CardNANO SIM
    CellularGlobal 4G
    BluetoothV2.1+EDR / V4.1 Dual Mode, Class 2
    WIFI802.11 ac/n/b/g/n
    WebUI

    Update firmware, manage settings and

    status, download data

    Electronic BubbleSupport
    Environment
    Dustproof&WaterproofIP67 (Customizable IP68)
    Humidity95% non-condense
    Power Supply
    BatteryRechargeable, built-in Lithium-ion battery,7.2 V - 10200 mAh
    Voltage9~28 V DC external power input
    Working TimeUp to 16 hours
    Charge TimeTypically 4 hours
    Internal Radio
    Frequency Range410 - 470 MHz
    ProtocolCHC, Transparent, TT450
    Emitting Power0.5 W / 2 W
    Operating Range5 km typically
